2005-2023 Tacoma Air Lift LoadLifter 5000 Rear Air Spring Kit 2WD/4WD
Rear air spring kit for the 2005-2023 Toyota Tacoma (2nd and 3rd Gen). Provides up to 5,000 lbs of load-leveling capacity for towing, hauling, and constant rear loads. Fits 2WD with axle-under-leaf configuration and all 4WD configurations.
Important Fitment Information:
- Does NOT fit 5-lug 2WD Tacomas with the axle ABOVE the leaf spring. 2WD models must have the axle UNDER the leaf spring.
- Frame drilling is required for installation — plan for additional install time vs. no-drill kits.
- If running a rear lift via add-a-leaf or lifted leaf pack, an airbag spacer may be required to prevent the bag from overextending. Lift blocks do not require a spacer.
Features
- 5,000 lb load-leveling capacity
- Air springs fully adjustable from 5–100 PSI for precise control
- 2-ply fabric construction with ultra-high-strength nylon composite end caps
- Roll plates protect the air springs from frame contact
- Frame drilling: Yes
- Limited Lifetime Warranty + 60-Day Ride Satisfaction Guarantee
Kit Contents (Part #57300)
- Two air springs
- Mounting brackets, air line, and fittings
- All required mounting hardware
- Schrader inflation valves (manual inflation — on-board compressor sold separately)
- Installation instructions
Replacement air spring: Air Lift PN 50225
Specifications
| Part Number | 57300 |
| Weight | 23.8 lb |
| Width | 14.125 in |
| Depth | 9.25 in |
| Height | 10.75 in |
| Replacement Air Spring | 50225 |
| Drilling Required | Yes |
| Application Type | Rear Kit |
Fitment
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2005-2015 | Toyota | Tacoma | Base |
| 2005-2015 | Toyota | Tacoma | Pre Runner |
| 2005-2013 | Toyota | Tacoma | X-Runner |
| 2016-2023 | Toyota | Tacoma | SR |
| 2016-2023 | Toyota | Tacoma | SR5 |
| 2016-2023 | Toyota | Tacoma | TRD Sport |
| 2016-2023 | Toyota | Tacoma | TRD Off-Road |
| 2015, 2017-2023 | Toyota | Tacoma | TRD Pro |
| 2016-2023 | Toyota | Tacoma | Limited |
| 2021 | Toyota | Tacoma | Trail |
| 2023 | Toyota | Tacoma | Trail Special Edition |
Installation
Download the manufacturer install guide: Air Lift Installation Manual (PDF).
